GENMAC KING-AIR RGU40DS

Silent generator with following specifications:

Frame:

• Heavy duty fabricated welded base plate with high quality steel UNI S235 JR
• Heavy duty, bell type, rubber anti-vibration mountings
• Dedicated area to make easier the electrical connection to the load
• Fuel tank with drain plug and retention basin
• Feet and four lifting holes on the base

Canopy:

• Large doors for easy access for service and maintenance
• Metalsheet Cut using high precision laser technology
• Weatherproof sealed joints
• Lockable handles in each door
• Grey RAL 7035 “orange peel” specific powder coat paint for outdoor usage
• Rain cap on exhaust outlet
• Fuel filler outside enclosure
• Ecological Sound foam: 100% Recyclable, 40mm thickness, fire-proof self-extinguishing class1 fire-reaction compliant washable, mechanically fixed to the frame

Muffler:

• Residential type, Supersilent
• Integrated in the canopy
• With aluminum coating

Control Panel:

• Self-standing control panel tower made with metal structure and components to grant IP65 protection, easily removable for maintenance
• Easy access to control panel through a canopy’s door, equipped with lexan window
• Control panel is divided in two independent and insulated boxes separating Controls (Controller and numbered terminal board) from Power connection (circuit breaker and cable inlet)
• External dedicated area to make easier the electrical connection to the load
• Power connection between circuit breaker and alternator made with high resistance neoprene cables (H07RNF) and using cable glands for waterproof connections
• All units and components are prototype tested, factory build and production tested. A specific control procedure during the several stages of production ensures long life and reliability.
